Lenovo disque SSD 480 Go M.2 PCI Express 4.0 NVMe 3D TLC NAND - 4XB7A82636

Lenovo  disque SSD 480 Go M.2 PCI Express 4.0 NVMe 3D TLC NAND - 4XB7A82636
Lenovo
SKU :
4XB7A82636 - Lenovo
Disponibilité :
Appelez/call 1-844-578-1008
$7,644.99
Largeur :
4.50 (pouces)
Hauteur :
1.00 (pouces)
Profondeur :
7.00 (pouces)

Contactez-nous !

Bien choisir cette référence

Cette référence utilise PCI Express 4.0 au format M.2. Elle ne peut pas fonctionner dans un emplacement M.2 limité au SATA ; le connecteur seul ne suffit pas à valider le remplacement.

La génération et le nombre de lignes PCIe de la machine peuvent limiter le débit. Vérifiez également la longueur de carte acceptée et le dégagement du dissipateur avant de remplacer un SSD existant.

FormatM.2
InterfacePCI Express 4.0
Capacité480 Go
Lecture annoncée5000 Mo/s
Comparer d’autres références de cette famille

Comparez ces caractéristiques ; ce tableau ne garantit pas la compatibilité avec votre machine.

RéférenceDifférences à examiner
4XB1N36072Format : M.2 · Interface : PCI Express 4.0 · Capacité : 512 Go
4XB7A13999Format : M.2 · Interface : PCI Express 4.0 · Capacité : 960 Go · Lecture annoncée : 6800 Mo/s
4XB1S30110Format : M.2 · Interface : PCI Express 5.0 · Capacité : 512 Go · Lecture annoncée : 12800 Mo/s

Valeurs techniques : fiche de cette référence. Principes de choix : Kingston — interfaces SATA, PCIe et formats M.2.

Before you choose this reference

This M.2 drive uses PCI Express 4.0. It will not work in a SATA-only M.2 slot; the connector shape alone does not establish compatibility.

The host PCIe generation and lane count can limit throughput. Also check the supported card length and heatsink clearance before replacing an existing SSD.

Form factorM.2
InterfacePCI Express 4.0
Capacity480 GB
Rated read speed5000 MB/s
Compare other references in this family

Compare these specifications; this is not a machine-specific compatibility guarantee.

ReferenceDifferences to check
4XB1N36072Form factor : M.2 · Interface : PCI Express 4.0 · Capacity : 512 Go
4XB7A13999Form factor : M.2 · Interface : PCI Express 4.0 · Capacity : 960 Go · Rated read speed : 6800 Mo/s
4XB1S30110Form factor : M.2 · Interface : PCI Express 5.0 · Capacity : 512 Go · Rated read speed : 12800 Mo/s

Specification values: this reference’s technical sheet. Selection guidance: Kingston — interfaces SATA, PCIe et formats M.2.

Lenovo 4XB7A82636, 480 Go, M.2, 5000 Mo/s

Caractéristiques

Caractéristiques
Capacité du Solid State Drive (SSD)480 Go
Facteur de forme SSDM.2
InterfacePCI Express 4.0
NVMeOui
Type de mémoire3D TLC NAND
composant pourServeur/Station de travail
Le chiffrement matérielOui
Taille du SSD M.22280 (22 x 80 mm)
Vitesse de lecture5000 Mo/s
Vitesse d'écriture700 Mo/s
Lecture aléatoire (4KB)280000 IOPS
Écriture aléatoire (4KB)40000 IOPS
Latence en lecture80 µs
Latence en écriture30 µs
Support S.M.A.R.T.Oui
ECCOui
Échange à chaudOui
Temps moyen entre pannes2000000 h
CertificationCE (Europe): EN55032, EN55024 Class B, RoHS FCC: CFR Title 47, Part 15, Class B UL/cUL: approval to UL-60950-1, 2nd Edition, IEC 60950-1:2005 (2nd Edition); EN 60950-1 (2006) + A11:2009+ A1:2010 + A12:2011 + A2:2013 BSMI (Taiwan): approval to CNS 13438, Class B, CNS 15663 RCM (Australia, New Zealand): AS/NZS CISPR32 Class B KC RRL (Korea): approval to KN32 Class B, KN 35 Class B W.E.E.E.: Compliance with EU WEEE directive 2012/19/EC. TUV (Germany): approval to IEC60950/EN60950 VCCI (Japan): 2015-04 Class B IC (Canada): ICES-003 Class B Morocco: EN55032, EN55024 Class B UkrSEPRO (Ukraine): EN55032 Class B, IEC60950/EN60950, RoHS (Resolution 2017 No. 139) UKCA (UK): SI 2016/1091 Class B and SI 2012/3032 RoHS



Puissance
Consommation électrique (Lecture)7 W
Consommation électrique (Ecriture)4,5 W



Conditions environnementales
Température d'opération0 - 70 °C
Température hors fonctionnement-40 - 85 °C
Humidité relative de fonctionnement (H-H)5 - 95%
Vibrations hors fonctionnement20 G
Choc durant le fonctionnement1500 G
Altitude maximale d'exploitation3050 m



MPN:
4XB7A82636
