HPE Aruba Networking AP-635 (RW) Tri Radio 2x2 802.11ax Wi-Fi 6E Internal Antennas TAA Campus AP, 2,4 GHz, 5 GHz, 6 GHz, 2400 Mbit/s, WPA, WPA2, WPA3, 2500,5000 Mbit/s
Caractéristiques
| Caractéristiques | |
| 2,4 GHz | Oui |
| 5 GHz | Oui |
| 6 GHz | Oui |
| Débit de transfert des données maximum | 2400 Mbit/s |
| LAN Ethernet : taux de transfert des données | 2500,5000 Mbit/s |
| Bande de fréquence | 20/40 (2.4 GHz), 20/40/80 (5 GHz), 20/40/80/160 (6 GHz), and maximum peak data rate 3.9 Gbps |
| Standards réseau | IEEE 802.11ax, IEEE 802.11mc |
| Bluetooth | Oui |
| Modèle du Bluetooth | 5.0 |
| MIMO (entrées multiples, sorties multiples) | Oui |
| Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
| GPS (satellite) | Oui |
| GLONASS | Oui |
| Sécurité | |
| Algorithme de sécurité soutenu | WPA, WPA2, WPA3 |
| Connectivité | |
| Nombre de port ethernet LAN (RJ-45) | 2 |
| Quantité de Ports USB 2.0 | 1 |
| Puissance | |
| Connexion Ethernet, supportant l'alimentation via ce port (PoE) | Oui |
| Design | |
| Positionnement | Plafond |
| Couleur du produit | Blanc |
| Utilisation recommandée | Intérieure |
| Antenne | |
| Type d'antenne | Interne |
| Type de direction d'antenne | Omni-directionnel |
| Fonctions de l’antenne | Antenne intégrée |
| Niveau de gain de l'antenne (max) | 7 dBi |
| représentation / réalisation | |
| Systèmes d'exploitation compatibles | AP-634 (excluding 6 GHz support): HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.11.2.0, HPE Aruba Networking Wireless Operating System 10.6.0.0 AP-634 (including 6 GHz support): HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.12.0.0, HPE Aruba Networking Wireless Operating System 10.7.0.03 AP-635: HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.9.0.0, HPE Aruba Networking Wireless Operating System 10.4.0.0 Standard power product class operation of the AP-634 is only supported on HPE Aruba Networking OS 10.7.0.0 and later deployments and HPE Aruba Networking OS 8.12.0.0 and later deployments that include a HPE Aruba Networking Mobility Conductor. Standard power operation is not supported on Instant OS deployments or 8.x HPE Aruba Networking OS deployments without a HPE Aruba Networking Mobility Conductor. |
| Certificat | |
| Certificats de conformité | Federal Communications Commission (FCC), ISED, CE, Compatibilité électromagnétique (CEM), Directive basse tension (DBT) |
| Certification | UL2043 plenum rating Wi‑Fi Alliance: Wi-Fi CERTIFIED a, b, g, n, ac Wi-Fi CERTIFIED 6E (ax, 6 GHz) WPA, WPA2 and WPA3—Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE) WMM, WMM-PS, W-Fi Agile Multiband Bluetooth SIG Ethernet Alliance (PoE, PD device, class 5) |
| Poids et dimensions | |
| Largeur | 220 mm |
| Profondeur | 220 mm |
| Hauteur | 51 mm |
| Poids | 1,3 kg |
| Autres caractéristiques | |
| Ports E/S | E0, E1: Two Ethernet wired network ports (RJ-45); Auto-sensing link speed (100/1000/2500BASE-T) and MDI/MDX; 2.5Gbps speed complies with NBase-T and 802.3bz specifications; POE-PD: 48Vdc (nominal) 802.3af/at/bt POE (class 3 or higher); 802.3az Energy Efficient Ethernet (EEE) |
| Montage | A mounting bracket has been pre-installed on the back of the AP. This bracket is used to secure the AP to any of the mount kits (sold separately). |
| Poids (impérial) | 1,3 kg (2.86 kg) |
| Conditions environnementales | |
| Humidité relative de fonctionnement (H-H) | 5 - 95% |
| Température d'opération | 0 - 50 °C |
| Température hors fonctionnement | -25 - 55 °C |
| Taux d'humidité relative (stockage) | 10 - 100% |
